McCallum General Engineering

Workshop

Outsourcing Maintenance & Machining Service

At McCallum General Engineering we can provide your business with an off-site machine workshop. We understand that setting up a machine shop takes time, money and precious space. What we offer is a place to outsource any machining needs you may have.

Simply call us with your needs and we will manufacture the parts you require as soon as possible. We keep large amounts of various materials on-site in order to ensure the fastest possible turn over. Additionally, if you are experiencing a problem or a breakdown situation we can work out-of-hours to ensure your machinery is up and running as quickly as possible.

Turning Capabilities
  • Manual lathes
  • 2 Schaublin 135 Lathes
  • Spindle bore 40mm
  • Center distance 630mm
  • Swing over bed 315mm
  • Elpha SJ 1760 G Lathe
  • Spindle bore 52mm
  • Center Distance 1500mm
  • Swing over bed 350
  • Dean Smith and Grace 2112 Lathe
  • Spindle bore 80mm
  • Center Distance 1200mm
  • Swing over bed 750mm
  • CNC Lathe
  • Daewoo Puma 8s
  • Spindle bore 50mm
  • Center distance 500mm
Milling Capabilities
  • Deckle FP2 Universal Mill
  • X 400mm
  • Y 200mm
  • Z 300mm
  • King Rich R4v Turret mill
  • Bed length 1920mm. With a 1500mm cut in one pass.
  • X 1500mm
  • Y 600mm
  • Z 500mm
  • CNC Mill
  • Extron B320 CNC machining Center with 4th axis
  • Table 1000mm x400mm
  • 16-tool turret
  • X 860mm
  • Y 500mm
  • Z 600mm
Horizontal Borer
  • Pfeifer F60 Horizontal Borer
  • Table size 650mmx500mm
  • Z 600mm
  • X 600mm
  • Y 500mm
Surface Grinder
  • Chevalier Surface Grinder
  • Stroke 450mm x 200 mm Width
  • Tool and Cutter Grinder
  • Cincinnati Tool and cutter no2
Sheet Metal Fabrication
  • Metal Master Hydraulic Pan Brake
  • 1200mm x 3mm
  • Metal Master Hydraulic Guillotine
  • 1200mm x 3mm
Welding
  • Mig welding
  • Tig welding both AC & DC
